Our Product Specifications
Note:T&T hose is available in a wide variety of lengths, dimensions and fittings to meet all your needs.
Item No | Type | Hose Dimension | Working Pressure | Burst Pressure | Net Weight | Measure | |
I.D | Length | ||||||
Inch | mm | m/roll | Bar | Bar | Kg/m | m³ | |
TLP-08025 | 1" | 25 | 100 | 8 | 25 | 0.15 | 0.0186 |
TLP-08032 | 1-1/4" | 32 | 100 | 8 | 25 | 0.17 | 0.0223 |
TLP-08040 | 1-1/2" | 38 | 100 | 8 | 25 | 0.2 | 0.0261 |
TLP-04050 | 2" | 51 | 100 | 4 | 12 | 0.22 | 0.0357 |
TLP-06050 | 2" | 51 | 100 | 6 | 18 | 28 | 0.0357 |
TLP-08050 | 2" | 51 | 100 | 8 | 25 | 0.3 | 0.038 |
TLP-04064 | 2-1/2" | 64 | 100 | 4 | 13 | 0.3 | 0.0465 |
TLP-06064 | 2-1/2" | 64 | 100 | 6 | 18 | 0.42 | 0.0465 |
TLP-03075 | 3" | 76 | 100 | 3 | 9 | 0.4 | 0.061 |
TLP-04075 | 3" | 76 | 100 | 4 | 12 | 048 | 0.063 |
TLP-06075 | 3" | 76 | 100 | 6 | 18 | 0.55 | 0.063 |
TLP-08075 | 3" | 76 | 100 | 8 | 25 | 0.6 | 0.0696 |
TLP-03100 | 4" | 102 | 100 | 3 | 9 | 0.53 | 0.0833 |
TLP-04100 | 4" | 102 | 100 | 4 | 11 | 062 | 0.0833 |
TLP-06100 | 4" | 102 | 101 | 6 | 18 | 0.95 | 0.086 |
TLP-03125 | 5" | 125 | 102 | 3 | 11 | 0.75 | 0.109 |
TLP-03150 | 6" | 152 | 100 | 3 | 11 | 0.9 | 0.141 |
TLP-03200 | 8" | 200 | 100 | 3 | 10 | 1.8 | 0.212 |
